2109-5G

2109-5G Description

Applications

Electronic Production / Rework

Features

• Fastest Cure – Dry to Touch in Under 10 Minutes!

• Faster Throughput without Capital Investment

• Thick Coating – One-Pass Application

• Fast & Easy Rework & Repair

• IPC-CC-830B & MIL-I-46058C Certified

• UL94 V-0

• Crystal Clear & Glossy Finish

• UV Indicator for Black Light QC Inspection

• MEK, Toluene & Xylene Free

Description

Techspray’s new Turbo-Coat HV Acrylic Conformal Coating is a high viscosity version of our popular Turbo-Coat. This coating is tested in approved in Asymtek and PVA selective spray systems, both atomized and airless modles.

Turbo-Coat is designed to speed up board production throughput without additional investment of expensive UV systems or other capital equipment. Conformal coating cure time is often considered a production bottleneck for PCB assembly operations. Turbo-Coat HV dries tack-free in under 10 minutes, allowing manufactures to handle boards in 1/2 the time of the leading acrylic coating!

Turbo-Coat Thinner is available to reduce the viscosity to fit ideal process parameters. Turbo-Coat, Turbo-Coat HV, and Turbo-Coat Thinner are all HAPs (Hazardous Air Polutants) free, so do not contain common coating solvents like Toluene, Xylene, and MEK. This makes these coating more user friendly and safe.

Turbo-Coat HV uses the same acrylic resin as the original Turbo-Coat, so coatings can be mixed-and-matched through the process, e.g. using the faster curing Turbo-Coat in the rework area, Turbo-Coat HV in the assembly ar
